Core Performance
- Processor Options (11th Gen Intel Tiger Lake H-Series):
- Intel Core i7-11800H (8 Cores, 16 Threads, up to 4.60 GHz, 24MB Cache).
- Graphics:
- Discrete: NVIDIA RTX A2000 (4GB GDDR6 dedicated video memory).
- Integrated: Intel UHD Graphics.
- Memory: 16GB Up to 64GB DDR4-3200 MHz via 2x SO-DIMM slots (Supports both Non-ECC and ECC memory options).
- Storage: 2x M.2 2280 PCIe Gen 4 x4 NVMe slots; supports up to 8TB total storage (RAID 0/1 capable).
Display Options (17.0-inch, 16:10 Aspect Ratio, InfinityEdge)
- WUXGA / FHD+ Standard: 1920 x 1200 resolution, IPS, 500 nits, 100% sRGB, anti-glare, non-touch.
Ports and Connectivity (All-Thunderbolt Layout)
- Thunderbolt Ports: 4x Thunderbolt 4 / USB4 Type-C ports (All four ports support Power Delivery and DisplayPort alt mode).
- Audio: 1x Universal Audio jack (3.5mm headphone/microphone combo).
- Expansion Slots: 1x Full-size SD card reader (SDXC up to v3.0), 1x Wedge-shaped lock slot.
- Networking: Intel Wi-Fi 6E AX210, Bluetooth 5.2. (Note: No native RJ-45 Ethernet port; requires a Type-C adapter).
Body, Power, and Dimensions
- Dimensions: 374.48 x 248.08 x 13.15 mm (14.74 x 9.77 x 0.52 inches).
- Weight:
- Starts at 2.13 kg (4.70 lbs) for the FHD+ non-touch layout.
- Up to 2.53 kg (5.58 lbs) for the UHD+ touch layout with the larger battery.
- Chassis Materials: Precision-crafted CNC Aluminum outer shell paired with a woven Carbon Fiber palm rest.
- Battery Options:
- 3-cell (56 Wh) Lithium-ion battery.
- 6-cell (97 Wh) Lithium-ion battery with ExpressCharge support.
- Power Adapter: 130W USB-C AC adapter.
Multimedia and Security
- Audio: Studio-quality quad speakers (2x 2W stereo woofers + 2x 2.5W tweeters) tuned by Waves MaxxAudio Pro.
- Camera: HD (720p) IR Camera with Windows Hello facial recognition and dual-array digital microphones.
- Keyboard: Backlit island-style keyboard (No dedicated numeric keypad layout).
- Security: Discrete TPM 2.0, Fingerprint reader integrated into the power button, Chassis intrusion switch.
